Evotek Piston Pressure Switch

EVPI-B

Configure EVOTEK products according to your requirements. Go to options to see all configuration possibilities.
Choose an option
Choose an option

Description

  • Piston pressure switch (adjustment knob with pressure scale)
  • Pressure settings :6 –630 bar
  • Working pressure: max. 650 bar
  • Repeatability: < ±1% of setting
  • Fluid temperature: -20°C to 75°C
  • Viscosity: 30 to 100 mm²/s (cSt) at 40°C
  • Recommended filtration: 25 μm
  • Compatibility: Suitable for hydraulic oils in compliance with DIN51524
