EVPC-03
Description
- CETOP03 Pressure relief valve
- Size: ND06 –ISO 4401-03 (CETOP03)
- Flow rate: max. 50 l/min in controlled linesmax. 75 l/min in free lines
- Pressure: max. 350 bar
- Ambient temperature range: -20 to 50 °C
- Fluid temperature range: -20 to 80 °C
- Fluid viscosity range: 10 to 400 cSt
- Recommended viscosity: 25 cSt
- Fluid contamination degree:according to ISO 4406: 1999 class 20/18/15
