EVDS-05
Description
- CETOP05 Solenoid controlled directional valve
- Size: ND 10 –ISO 4401-05 (CETOP 05)
- Flow rate: max. 150 l/min
- Pressure: max. 320 bar on P, A & B portsmax. 210 bar on T port (DC version) max. 140 bar on T port (AC version)
- Ambient temperature range: -20 to +50°C
- Fluid temperature range: -20 to +80°C
- Fluid viscosity range: 10 to 400 cSt
- Recommended viscosity: 25 cSt
- Fluid contamination degree: according to ISO 4406:1999 class 20/18/15
