EAVL-T
Description
Product Description
- Can be dismounted without removing the tank cap
- Direct mounting on tank lid
- Level and temperature control in the tank
- Suitable with many different fluids
- With any length up to 1000mm possible
Technical Specifications
- Application Electromagnetic level switches
- Port Sizes: Fastening by means of flange or screw connection
- Flange/Threaded body: Aluminium
- Seals: NBR or FPM or EPDM
- Tube: Stainless Steel
- Float: Stainless Steel
- Temperature range: -25°C to 110°C
- Instrument plug: DIN43650A
- Degree of protection: IP65
- Switching current: Level: max. 1.3 A/ Temperature: 2 A
- Switching voltage: Level: max. 220 V AC / 50 V DC;Temperature: max. 220 V AC / 50 V DC
- Switching power: 80 W
- Temperature switching point: 60/70/80°C
- Temperature accuracy: ± 10%
- Contact functions: Normally closed or normally open
